With the plate heat exchanger, moisture separator, interconnecting piping and flanges, all made from stainless steel to prevent corrosion. Refrigerant gas is ozone friendly R134A or R410A. Dew Point Alarm-option- displayed on compressor control panel and on dryer unit to help maintain the quality and security of the air supplied for blow moulding.
With the plate heat exchanger, moisture separator, interconnecting piping and flanges, all made from stainless steel to prevent corrosion. Refrigerant gas is ozone friendly R134A or R410A. Dew Point Alarm-option- displayed on compressor control panel and on dryer unit to help maintain the quality and security of the air supplied for blow moulding.
•Pressure Dew Point(PDP): 2~10℃
•Capacity :3.6m3/min
•Max.Working pressure :16bar
•Max. inlet temperature : 65℃
•Refrigerant:R410A
•Max. Ambient temperature:50℃
•Min. ambient temoperature:3℃
•Cooling type :Air-cooling
Compressed air system:
Air dryer work flow chart:
Stainless steel plate heat exchanger and air connection pipe.
• High efficiency plate heat exchanger with counter-flow on both
air-to-air and air-to- refrigerant sides for efficient heat transfer. As the outgoing air is reheated, it protects the outlet
piping against pipe sweating.
• Pressure dew point 3-5℃
• SH seires dryer have passed latest CE certification with multiple
overload protection devices configured. •Environmental refrigerant.
1.2m3/min - 13m3/min refrigerated air dryer parameters:
Air dryer | ||||||||
Model number | unit | RM-TR01 | RM-TR02 | RM-TR03 | RM-TR06 | RM-TR08 | RM-TR10 | RM-TR12 |
Air flow | m3/min | 1.2 | 2.4 | 3.6 | 6.5 | 8.5 | 10.5 | 13 |
Voltage | v/hz | 220V/50HZ 1PHASE | ||||||
Power | kw | 0.37 | 0.52 | 0.735 | 1.26 | 1.87 | 2.43 | 2.63 |
Air in/outlet connection | R3/4" | R3/4" | R1" | R1 1/2" | R2" | R2" | R2" | |
Evaporator | Aluminum alloy plate | |||||||
Way of cooling | Air cooling, Tube fin | |||||||
Refrigerant | R134A | R410A | ||||||
Controller/Protection functions | ||||||||
Interface | LED dewpoint display, LED error code display, Running status indication | |||||||
Frost protection | Constant pressure expansion valve | |||||||
Temperature control | Condensing temperature, dewpoint control automatically | |||||||
High voltage protection | ||||||||
Low voltage protection | ||||||||
Net Weight | kg | 34 | 42 | 50 | 63 | 73 | 85 | 94 |
Dimensioin (LxWxH) | mm | 480x380x665 | 520x410x725 | 640x520x850 | 700x540x950 | 770x590x990 | 770x590x990 | 800x610x1030 |
More photos, welcome to contact with us for catalog and quotation sheet, thank you.
Packaging & Shipping
Screw air compressors package Oil-free Scroll air compressors 200bar-300bar Air compressors
For our screw air compressors, we packed them by plywood case for LCL shipping, for full container shipping, we will pack the air compressors depend on customer request, sometimes by pallet too. | We packed all of our oil-free scroll air compressors by plywood case, because they take not much big space, and for good safe transport, if oil-free scroll airend, we will pack them by pp foam first, after that by plywood case. | For our small breathe air compressors,we all packed them by plywood case, normally they are 2.2kw 225bar or 330bar pressure, take very small space, for scuba diving and firefighting breathe air. |
Company Information
Shanghai Royal Machinery Co.,Ltd is a professional company of industrial air compressors, air treatment and air compressor spare parts, with engineers and sales people who have over 8 years experience, Royal Machinery has two business divisions, one is our own brand products, the other brands are Ingersoll Rand and Compair products. We have been marketing industrial compressed air equipment to global market since 2017 and the main assembling plants cover more than 50,000 square meters and 320 employees. The range of our compressors supplying start from the smallest compressors used by individuals to very large compressors used in heavy industrial applications. We started the business as a close partner to our customers, our sales team can provide you competitive price with high quality products, with our customers supporting, our team will get all the orders fulfilled on time and provide you excellent after-sales service. Our product range represents the most comprehensive portfolio of compressed air equipment offered for thousands of applications in the Oil, Textile, Food, Marine, Mining and many other industries. Our products consist of medium and high pressure reciprocating compressors, oil-injected screw compressors, oil free screw compressors, vane compressors, centrifugal compressors, portable compressors, CNG compressors and CNG related equipment, also high pressure scuba air compressors. Our mission is to bring China assembled compressors of good quality and service, with attractive price for all the customers all over the world. You are welcomed to be developed with us together for a fruitful future.
Wecome to contact us for more details, we will offer compressor details, oil free screw air compressor use manual, oil free screw air compressor configuration list, oil free screw air compressor instruction drawings, spare parts list, installation drawings, technical support and maintenance training.
FAQ
1. What's the warranty of your air compressors
we give screw airend 2 years warranty, complete compressor unit 1 year; oil-free scroll air compressors we give 2 years warranty.
2. Can you do OEM?
Yes, we accept OEM and ODM orders for all our air compressors.
3. What is the delivery time of the air compressor?
It depend on customer order quantity, for regular voltage and pressure air compressors, our lead time 7 days, if big quantity we need 10-20days to prepare.
4. What's the MOQ
We accept all of our air compressors MOQ 1 unit.
5. Can your air compressors work at high ambient temperature like 50℃ above please?
Yes, our oil injection screw air compressors are support to work at high temperature environment, for oil-free water-lubrication screw air compressors, we will design it to be with air cooling or water cooling according to ambinet temperature.
6. Can your air compressor work at low temperature like -20℃ below?
Yes our air compressor is working very good in area like North of China and Russia.
7. Do you have installation or maintenance video?
Yes, we can offer our air compressor installation and maintenance video to customers.
